　　applications: general lab. testing, robotics and machine control, marine and flight testing, automotive testing
i
　　ndustries: medical

　　description: epb is a small pressure probe sensor, small profile, stainless steel, flush mount transducer designed for general media. epb is offered in pressure ranges from 0-5 to 5000 psi (0-0.35 to 350 bar), vented, sealed, and absolute pressure. epb's overall diameter can be as small as 3.2 mm (0.125"). resonant frequency 55 through 400 khz makes it suitable for both static and dynamic measurements. various compensated temperature ranges are available from -40°c up to 90°c.

　　features:
　　available ranges 0-5 to 5000 psi (0-0.35 to 350 bar)
　　stainless steel construction
　　resonant frequency 55 through 400 khz
　　non repeatability : 0.25% fso
　　ce approved

　　典型应用: 一般实验室测试，机械人和机械控制，船舶和飞行测试，汽车测试

　　行业: 医疗

　　产品描述: epb小型压力传感器体积小，采用齐平膜式不锈钢结构，用于一般介质测量，量程从0-5到5000psi（0-0.35到350bar），包括表压，密封压和绝压。epb的直径可以小到3.2mm（0.125"），响应频率从55到400khz，适合动态和静态测量。-40°c 到90°c之间多种补偿温度范围可选。

　　特点:
　　测量量程：0~5到5000psi（0~0.35到350bar）
　　不锈钢结构
　　响应频率：55~400khz
　　非重复性：0.25%fso
　　ce认证

　　epb小型传感器更多技术参数及规格书下载请浏览：http://www.sensorway.cn/sensors/181.html
　　
　　北京赛斯维测控技术有限公司产品咨询热线：010-84775646，84775648。
