　　applications: sports and recreation, modeling, biodynamics, pedestrian crash testing
industries:

　　description: the model egas3 is a cube-shaped, triaxial accelerometer with frequency response to 3500 hz. operating from 15 vdc, this unit features a transverse sensitivity of 2% max and damping of 0.7 overrange stops ensure survivability of the unit under extreme shock conditions wihle its temperature performance offers a minimal zero shift of ± 1 mv per 50°c. with rugged, shielded cables, these units are well-suited for a wide range of high-impact studies.

　　features:

　　small size
　　static and dynamic measurement
　　frequency response through 3500 hz
　　2% transverse sensitivity
　　damping ratio 0.7

　　典型应用: 运动，模型，生物动力学，行人碰撞测试

　　产品描述:

　　egas3是一款正方体的，响应频率可达3500hz。产品的工作电压为15vdc，最大横向灵敏度为2%，阻尼比为0.7，内置过载限位保护大发电子平台游戏官网不被极限冲击的损坏。大发电子平台游戏官网温度性能好，每50℃的最小零点偏移为±1mv，坚固的屏蔽电缆，主要应用于高冲击研究。

　　特点:

　　小尺寸
　　静态和动态测量
　　响应频率可达3500hz
　　2％横向灵敏度
　　阻尼比0.7

　　egas3加速度传感器更多技术参数及规格书下载请浏览：http://www.sensorway.cn/sensors/112.html

　　北京赛斯维测控技术有限公司产品咨询热线：010-84775646，84775648。
