- ms5212-hm压力传感器中英文产品介绍
- 来源：大发电子平台游戏官网 发表于 2014/10/15
applications: absolute pressure sensor systems, high resolution altimeters/variometers, barometers, engine controls, tire pressure, diver's computers
description: the ms5212-hm pressure sensor series is designed for pressure systems with the highest demands on resolution and accuracy. the ms5212-hm is a 12bar high-linearity version dedicated for high-endurance applications: the device consists of a silicon micromachined pressure sensor die mounted on a 7.6 x 7.6 mm ceramic carrier protected by a metal cap.
features:
low-cost smd ceramic package
high-reliability, low-drift
-40°c to 125°c operation range
optional: gel protection against humidity and water
high endurance pad technolog
典型应用: 绝对压力测量系统，高分辨率高度计，大气压力计，气压表，发动机控制，潜水设备，轮胎压力
产品描述:
ms5212-hm压力传感器适用于高分辨率、高精度的压力测量系统。传感器基于硅压阻技术，封装在7.6×7.6mm的陶瓷基板上，由金属环保护，量程为12bar，线性度高，非常适合需要长寿命大发电子平台游戏官网的应用。
特点:
低成本smd陶瓷封装
高可靠性，漂移小
-40°c ~ 125°c工作温度范围
可选：封胶防潮防水
寿命长
